Image Analysis Help/Limitations?
Franklin  [23 posts] 		16 year

Hello,

I have an image composed of rectangles (black and red), logos and some text.  I’m try to find where the rectangle (or rectangle corners) on the page.  The text and logo don’t really matter.    Also, some of the rectangles have spurs on the edges

1)    After converting to binary Clean and Spur don’t seem to work on the  whole image (maybe it is too large)
2)    I can’t seem to separate the large (black) and smaller (red) rectangles on the page


-    Any hints

Thanks in advance


-Franklin
Here is a sample picture
Franklin  [23 posts] 		16 year

Sorry for the double posting
